Why PAW 850
Man Made Continues Filament yarn precision assembling and intermingling winder
- Watch our video
Process:
Required Air Pressure: Min. 3 Bar / Max. 6 Bar depends on process parameter and finish product requirement.
Min./Max. No. Of positions: Min. 16 (SS) & 32 (DS) / Max.112 (SS) & 224 (DS)
M/C Mechanical Speed: 1200 Meter/min. Over feed speed, 1000 Meter/Min. Take up speed
M/C Power Consumption: Max.0.1 Kwh per Position processing 150 Denier ITY @ 700 Meter/Min. process speed, which depends on machine maintenance, end product quality requirement and ambient condition.
Feed Creel: Box type, close yarn path, 2+2, rotating package holder per position and PAW 850-4/8P with 4+4 package holder per position
Yarn Feed Shafts:
– Feed Shafts (W1) with Apron nipping: One Feed shaft / position before intermingling jet
– Delivery Shaft (W2) with apron Nipping: One Feed Shaft / position after Intermingling Jet
Intermingling Zone: Sectional intermingling jet mounting manifold with necessary air line within the machine
Tack – Up Head:
– Manual doffing
– 6/12/18 degree Bi-conical package build up
– 57 OR 69 mm Diameter, 280/290 mm paper tube length
– Max package Diameter: 240mm.
– Max Package Wt.: 6.5 Kg. @80~100 finish denier
– Traverse speed: Up to 600 CPM
– Multi stroke, axial winding program
Oiling Device: 64 mm. Diameter grooved oil Roller
Air Header Lines: Compressed air line within the machine without pressure regulator and air filters.
Add on / alternate optional supply for enhancing specific ITY product quality and productivity.
Rotary Creel (R/C): Rotary creel facilitates loading of creel from either side of the creel
Fancy Yarn Devices:
Close loop control: Encoder feed back close loop controlled all motor for better speed holding accuracy
Intermingling Jet: Intermingling Jet Core, housing and QRC according to denier range to be processed.
Spandex (Elastomer) Feeder: Spandex drafting/feeding with shortest possible and straight yarn path.
Hard/Soft Package Formation: Take Up Cradle with pressure adjustment through dead weight to produce regular and soft package for yarn dying application
Doff Timer: Doff timer for random, sectional or side/machine wise equal length doffing indications and production efficiency monitoring system
Machine Lay Out: 2 Deck Take Up, Single (SS) / Double (DS) sided machine
Machine Length / Width / Height:
No. Of Position SS / DS: | 56/112 | 64/128 | 72/144 | 80/160 | 88/176 | 96/192 | 104/208 | 112/224 |
Machine Length with | 12.2 | 13.6 | 15 | 16.4 | 17.8 | 19.2 | 20.6 | 22 |
Closed Door (meter) | ||||||||
Machine Width: Version 2/4 Ply (SS/DS) | ||||||||
——— SS: 3.6 meter (11’ 10”Feet) / DS: 6.1 meter (20’ feet) ——– | ||||||||
Machine Width: Version 4/8 Ply (SS Only) | ————- SS: 4.82 meter / 15’ 6” feet —————— | |||||||
Machine Height | 2.65 meter / 8’ 9’’ feet (With Spandex feed: 2.75 Meter / 9’3” feet) |
No. Of Position, | |||||||||
Single Sided Machine, (SS): | 48 | 56 | 64 | 72 | 80 | 88 | 96 | 104 | 112 |
Double Sided Machine, (DS): | 96 | 112 | 128 | 144 | 160 | 176 | 192 | 208 | 224 |
Total Power (KW): | |||||||||
Single Sided Machine (KW): | 13.5 | 15 | 16.5 | 16.5 | 18 | 19.5 | 22.5 | 22.5 | 22.5 |
Double Sided Machine (KW): | 21 | 24 | 27 | 27 | 30 | 33 | 39 | 39 | 39 |
Man Made Continues Filament yarn precision assembling and intermingling winder
